XL-3528SURC is a high brightness red LED packaged in XINGLIGHT 3528, with typical parameters as follows:
Peak wavelength 615-630 nm, main wavelength 625 nm
Forward voltage 2.4 V, rated current 20 mA, luminous intensity 300-550 mcd
120 ° viewing angle, colorless transparent lens, front mounted package
Working temperature -40 ℃~+85 ℃, compatible with reflow soldering, compliant with RoHS
outline Dimensions(L / w / h): 3.5*2.8*1.9mm
Luminous color and colloid: Red/water colloid
Environmental protection products Complied With ROHS Directive
Moisture sensitivity level（MSL）: 3 levels
EIA standard packaging
Suitable for SMT automatic production
Suitable for infrared reflow soldering process
Indoor lighting
Auxiliary lighting
Advertising module lighting
Luminescent character
Counter lighting
Shop lighting
Jewelry display cabinet lighting
