XL-3216IRC-940 is a 1206-packaged 940nm infrared emitting diode, measuring 3.2×1.6×0.8mm with a transparent colloid. Compliant with ROHS and MSL Grade 3, it’s suitable for SMT automatic production. It has a max forward current of 30mA, peak pulse current of 100mA, forward voltage of 1.0-1.5V, radiant intensity of 1-10mW/sr, 120° viewing angle, and 2000V ESD protection. Operating and storage temperature ranges are -40~+85℃, with soldering requirement of 260℃≤6s. Ideal for intelligent appliance iris recognition, infrared luminescent micro light barriers, photoelectric switches, smoke detectors, etc.
Outline Dimensions (L / w / h): 3.2*1.6*0.8 mm
Color and colloid: infrared 850nm / water colloid
Environmental protection products Complied With ROHS Directive
Moisture sensitivity level（MSL）: 3 levels
EIA standard packaging
Suitable for SMT automatic production
Suitable for infrared reflow soldering process
Intelligent product household appliance iris recognition ；
Infrared luminescent micro light barrier
floppy disk driver
Photoelectric switch
Smoke Detector
infrared sensor
Induction switch
