The XL-DZ304SURD/4 F3MM red four-pin LED is designed for F3MM specification four-pin sockets, featuring red encapsulation and primarily red light. The dimensions are 20.3×10.7×4.5mm. It complies with ROHS standards, has an MSL2 rating, uses EIA standard packaging, offers long service life, low maintenance cost, high energy efficiency, and quick start-up. Operating temperature range is -40℃ to 85℃, storage temperature range is -40℃ to 85℃, forward current per LED is 20mA (total 80mA for four pins), voltage is 1.8-2.4V, luminous intensity is 300-1500mcd, main wavelength 615-635nm, and emission angle 45°.
Appearance dimension: 20.3*10.7*4.5mm
Luminous color and colloid: Red Light /Red colloid
Environmental protection products meet ROHS requirements
Moisture sensitivity level（MSL） :2 levels
EIA standard packaging
Long operating life
Reduced maintenance costs
High energy efficiency, fast startup
Internet of Things
medical treatment
converter
Storage servers and communication
Status indicator
Electronic testing instruments
