XL815-G
Z6·尊龙凯时「中国」官方网站
XL815-G

Case: DIP4、DIP4-M、SMD4


Molding Compound: UL Flammability Classification Rating 94V-0


Terminals: Matte tin-plated leads; solder ability-per MIL-STD-202, Method 208

Z6·尊龙凯时「中国」官方网站
PDF EDA Model
Product Characteristics

● Current transfer ratio(CTR: 600~7500% at IF =1mA, VCE = 2V)


● High isolation voltage between input and output (Viso =5000Vrms )


● Operating Temperature: -55℃~110℃


● Environmentally friendly products, compliant with CQC, UL, and VDE requirements

Product Application
● It is widely used in the feedback control loops of switching power supplies and the isolation between main circuits and control circuits, ensuring stable output voltage and quickly transmitting fault signals to trigger protection mechanisms in the event of overload or short circuit.

● Photovoltaic energy storage system

● Data collection, inverter control, protection circuit

● Industrial automation control

● Relay drive, motor control, PLC interface

● Power management

● Switching power supply feedback isolation、Home appliance power control
