XL-2106IRC-940 is a 0802-packaged 940nm infrared emitting diode, measuring 2.1×0.55×1.0mm with a transparent colloid. Compliant with ROHS and MSL Grade 3, it’s suitable for SMT automatic production and reflow soldering. It has a max forward current of 30mA, peak pulse current of 100mA, forward voltage of 1.0-1.5V, radiant intensity of 1-5mW/sr, 120° viewing angle, and 2000V ESD protection. Operating and storage temperature ranges are -40~+85℃, with soldering requirement of 260℃≤6s. Ideal for medical equipment, infrared remote controls, camera monitors, industrial control, etc.
Outline Dimensions (L / w / h)：1.6 x 0.6 x 1.1mm
Color and colloid: infrared 950nm / water colloid
Environmental protection products Complied With ROHS Directive
Moisture sensitivity level（MSL）： 3 levels
EIA standard packaging
Suitable for SMT automatic production
Suitable for infrared reflow soldering process
Medical equipment
Infrared remote controller
Camera monitoring head
Industrial control: counters, thermal imaging, smart meter
Infrared photoelectric switch
Wireless communication and signal transmission
Intelligent car, robot
