XL-HD3535HIRC-T4A2 is a 3535-packaged 850nm infrared emitting diode, featuring a 3535EMC package support and colorless transparent colloid. It boasts outstanding power and current specifications: power dissipation of 1000mW, maximum continuous forward current of 700mA, peak pulse forward current of 2000mA, and forward voltage of 1.4-2.3V (IF=350mA). With a radiant intensity of 180-300mW/Sr (typical 200mW/Sr, IF=350mA), peak wavelength of 855nm, half wave width of 35nm, 120° viewing angle, maximum reverse current of 10μA, junction temperature of 115℃, and excellent ESD protection. Both operating and storage temperature ranges are -40~+85℃, with reflow soldering requirement of 255℃≤6s. Ideal for medical equipment, infrared remote controls, camera monitors, industrial control, infrared photoelectric switches, etc.
Outline Dimensions (L/W/H)：3.5*3.5*1.6 mm
Luminous color and colloid：infrared （invisible）850nm / colorless transparent silica gel
Packaging glue：3535EMC
Environmental protection products Complied With RoHS Directive
Moisture sensitivity level（MSL）：3 levels
Suitable for reflow soldering process
Medical equipment
Infrared remote controller
Camera monitoring head
Industrial control: counters, thermal imaging, smart meter
Infrared photoelectric switch
Wireless communication and signal transmission
Intelligent car, robot
