XL-234UYC-L 234 White Hair Yellow Long Lead LED is designed for 234 package long lead, with white colloid, mainly emitting yellow light, with dimensions 3.0×2.0×4.0×28mm. Compliant with ROHS standards, MSL2 grade, supports low voltage DC drive, long service life, and fast start. Operating temperature range -20℃~85℃, storage temperature range -40℃~85℃, forward current 20mA, voltage 1.8-2.4V, luminous intensity 50-300mcd, dominant wavelength 585-595nm, beam angle 110°.
Suitable for various scenarios such as household appliances, digital communications, automotive electronics, lighting fixtures, and traffic indicators, and can also be used in electronic toys, medical beauty instruments, etc. Soldering should be performed at least 2mm above the colloid base, wave soldering temperature ≤240℃/6S, manual soldering ≤300℃/3S; storage should be ≤30℃/70% RH, recommended to use within 3 months after opening, and anti-static protection should be ensured (HBM<1000V).
Appearance dimension: 3.0*2.0*4.0*28mm
Luminous color and colloid: yellow brightness White /water colloid
Environmental protection products meet ROHS requirements
Moisture sensitivity level（MSL） : 2 levels
EIA standard packaging
Long operating life
High energy efficiency, fast startup
Low voltage DC drive
Home appliances, digital, communication
Automotive Electronics
Lighting decoration
electronic toy
electronic clock
Traffic instructions
Medical beauty instruments
Electronic teaching equipment
Urban lighting
