XL-DZ304UGD/2 F3MM green hair green dual-hole lamp holder LED is designed for F3MM standard dual-hole lamp holder, with green colloid, primarily emitting green light, dimensions 10.0×9.0×4.5mm. Compliant with ROHS standards, MSL2 level, packaged according to EIA specifications, long service life, low maintenance cost, high energy efficiency, quick start. Operating temperature range -40℃~85℃, storage temperature range -40℃~85℃, single forward current 20mA (total current for dual-hole 40mA), voltage 2.6-3.4V, luminous intensity 2000mcd, dominant wavelength 515-530nm, light emission angle 45°. Suitable for IoT, medical devices, converters, storage servers and communication equipment, status indicators, electronic testing instruments and other scenarios.
Appearance dimension :10.0*9.0*4.5mm
Luminous color and colloid:green Light /green colloid
Environmental protection products meet ROHS requirements
Moisture sensitivity level（MSL） : 2 levels
EIA standard packaging
Long operating life
Reduced maintenance costs
High energy efficiency, fast startup
Internet of Things
medical treatment
converter
Storage servers and communication
Status indicator
Electronic testing instruments
