XL-DZ304UYSYGW/1 is an F3MM frosted single-die LED lamp holder launched by XINGLIGHT, measuring 7.5*6.5*4.5mm, with white-yellow and standard green dual colours. The main wavelength of the yellow light is 585-595nm and the standard green light is 565-575nm. The yellow light intensity is 300-900mcd and the standard green light intensity is 50-200mcd. The product complies with ROHS standards, has an MSL rating of 2, is anti-static up to 2000V, and operates at temperatures from -40℃ to 85℃. It features long life, high energy efficiency, and fast start, suitable for IoT, medical devices, status indicators and various other applications.
Appearance dimension (L / w / h): 7.5*6.5*4.5mm
Luminous color and colloid: yellow and green Light /Mist like colloidal color
Environmental protection products meet ROHS requirements
Moisture sensitivity level（MSL） : 2 levels
EIA standard packaging
Long operating life
Reduced maintenance costs
High energy efficiency, fast startup
Internet of Things
medical treatment
converter
Storage servers and communication
Status indicator
Electronic testing instruments
