The XL-D76765UYC is a yellow LED with a straight-in piranha package, featuring an F5 dome shape (round top, 5.0mm high) and overall dimensions of 7.6×7.6×2.5×5.0mm. It uses transparent epoxy, meets ROHS environmental standards, and has a moisture sensitivity level of MSL 2. This device has low power consumption and drive current (200mW/60mA), with a typical luminous intensity of 4000mcd and a 90° beam angle. It delivers good central brightness even at low power, making it suitable for indicator and lighting applications that require decent brightness and focused angles.
Optical Performance:
Emitting Color: Yellow (transparent colloid, F5 round-top package)
Dominant Wavelength (λd): 585~595nm (typical peak wavelength 588nm)
Luminous Intensity (IV): 3000~4000mcd (@60mA, typical value 4000mcd)
Viewing Angle (2θ1/2): 90° (angle is relatively focused, center brightness is good)
Spectral Width (Δλ): 20nm (typical value)
Electrical Parameters (Ta=25℃):
Power Consumption: 200mW
Maximum Forward Current (IF): 60mA
Forward Pulse Current (IFp): 240mA
Forward Voltage (VF): 1.8~2.4V (@60mA)
Reverse Current (IR): ≤10μA (VR=5V)
Environment and Reliability:
Operating Temperature: -20℃~85℃
Storage Temperature: -40℃~85℃
Soldering Heat Resistance: Wave soldering 240℃ ≤6s, manual soldering 300℃ ≤3s, solder joint should be at least 2.0mm above the bottom of the colloid
Passed 1000-hour lifespan test, high temperature and high humidity (85℃/RH 85~90%), thermal cycling (-40℃~100℃), thermal shock (-45℃~105℃), and lead bending reliability tests
Other:
Packed in EIA standard moisture-proof and anti-static bags
Supports screening by brightness, voltage, and wavelength to make batch selection easier
Outdoor Signage and Lighting: Backlighting for advertising light boxes, large font luminous modules, outline lights for city buildings, outdoor displays; suitable for yellow lights in traffic signals, with a 90° angle concentrating the light, ideal for lighting scenarios that need some directionality.
Industrial and Public Facilities: Status indicator lights for industrial equipment, emergency lighting, commercial lighting, indoor plant supplemental lighting.
Consumer Electronics and Home Appliances: Decorative light strips for home appliances, work status indicator lights.
Automotive Lighting: Can be used for turn signals, dashboard backlighting, interior indicator lights, etc. (with enough brightness and focused angles, suitable for signal indication).
