XL-408RGBC-WS2812B is an F5 package through-hole RGB color-changing LED launched by XINGLIGHT, featuring a transparent encapsulant. It integrates an externally controlled single-wire cascade constant current IC and RGB chips, eliminating the need for complex peripheral circuits and enabling infinite cascade connection and 256-level grayscale adjustment with natural and gorgeous color transitions.
This product complies with the RoHS environmental protection standard and is rated at MSL Level 2, compatible with SMT automated production and infrared reflow soldering. Both the operating and storage temperature ranges are -40℃~+85℃, with an ESD resistance of 2000V and a supply voltage of 3.5-5.5V. The RGB single-channel output current is 12mA and the data transmission frequency reaches 800Kbps, delivering stable performance and flexible control.
outline Dimensions (L / w / h)：5.8*4.8*5.0*28.2mm
Luminous color and colloid：Colorful magic/Transparent colloid
Environmental protection products Complied With ROHS Directive
Moisture sensitivity level（MSL）：2 levels
EIA standard packaging
Suitable for SMT automatic production
Led full-color luminous word lamp string
led full-color module
Led magic color soft and hard light strip, LED guardrail tube
Led appearance, scene lighting
Led heterosexual screen
All kinds of electronic products, electrical equipment, runninglights
