XL-B504RGBW F5 seven-colour long-leg diffused common-anode LED features an F5 package with long-leg design, diffused colloid, focused on RGB seven-colour light, common-anode type, with dimensions of 5.8×5.0×8.7×28mm. Complies with ROHS standards, MSL2 grade, long lifespan, fast start-up. Operating and storage temperature range: -40℃ to 85℃, forward working current: 20mA, red voltage: 1.8-2.4V, green/blue voltage: 2.8-3.4V, light intensity: red 700-1800mcd, green 4000-6000mcd, blue 1000-1500mcd, main wavelength: 460-630nm, viewing angle: 35°, ESD protection: 2000V. Suitable for backlight modules, automotive interiors, signal indicators, smart home, general lighting and other applications.
Appearance dimension:F5/5.8*5.0*8.7*28mm
Luminous color and colloid: Highlight RGB/Mist colloid
Environmentally friendly products, meeting ROHS requirements
Moisture sensitivity level（MSL） : 2 levels
EIA standard packaging
Long operating life
High energy efficiency, fast startup
Backlight module application
Automotive Interior Applications
Signal indication application
Smart Home Applications
General lighting applications
